Video



Video type



ATI Rage XL PCI video card; VGA connector



Video memory



8 MB

Power



DC power supply



NOTICE:

Ensure that the voltage selection switch on the power supply is set to the appropriate voltage

before turning on the power. See

Figure 1

-2

for the location of the switch.



Wattage



250 W



Voltage



At 50/60 Hz, 90–135 V at 6 A max and 180–265 V at

3 A max



Heat dissipation



910 BTU/hr



Maximum inrush current



Under typical line conditions and over the entire

system ambient operating range, the inrush current
may reach 25 A per power supply for 10 ms or less.



Batteries





System battery



CR 2032 3.0-V lithium ion coin cell

Physical



Height



42.7 cm (16.8 inches)



Width



19.1 cm (7.5 inches)



Depth



45.0 cm (17.7 inches)



Weight (maximum configuration)



12.7 kg (28 lb)

Environmental



Temperature



Operating

 10° to 35°C (50° to 95°F)



NOTE:

At 35°C (95°F), the maximum operating

altitude is 914 m (3000 ft).



Storage

 –40° to 65°C (–40° to 149°F)



Relative humidity



Operating



20% to 80% (noncondensing)



Storage



5% to 95% (noncondensing)



Maximum vibration



Operating



0.25 G at 3–200 Hz at 0.5 octave/min



Storage



0.5 G at 3–200 Hz at 1 octave/min



Maximum shock



Operating



Bottom half-sine pulse with a change in velocity of

50.8 cm/s (20 inches/s)



Storage



Nonoperating (half-sine pulse) 105 G, 2 ms



Nonoperating (faired-square wave) 27 G with a

velocity change of 508 cm/s (200 inches/s)



Altitude



Operating

 –

15 to 3048 m (–50 to 10,000 ft)



Storage

 –

15 to 10,600 m (–50 to 35,000 ft)
