Installing the Camera
1. Connect the LVDS and camera cable.
2. Place the camera module in its slot in the computer.
3. Tighten the screw to secure the camera module.
4. Install:
a) display bezel
b) battery
5. Follow the procedures in After Working Inside Your Computer .
Removing the Speakers
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove:
a) battery
b) SD card
c) base cover
d) keyboard
e) palmrest assembly
3. Remove the screws that secure the speakers to the computer and remove the speaker cable from their routing tabs
and remove the speakers from the computer.
