System Components
Dell Inspiron™ 6000 Service Manual
Back to Contents Page
NOTICE:
Only a certified service technician should perform repairs on your computer. Damage due to servicing that is not authorized by Dell is not
covered by your warranty.
NOTICE:
Unless otherwise noted, each procedure in this document assumes that a part can be replaced by performing the removal procedure in
reverse order.
1 display assembly
9
main battery
2 hinge cover
10 optical drive
3 keyboard
11 speakers
4 palm rest (with touch pad) 12 fan
5 system board assembly
13 microprocessor
6 computer base
14 microprocessor thermal-cooling assembly
7 Mini PCI card
15 video card/thermal-cooling assembly (optional)
8 hard drive
16 LED board
