9. Disconnect the touch-pad connector from the system board.
10. Lift the palm rest and remove it from the computer.
Replacing the Palm Rest
1. Align the palm rest with the computer base, and connect the touch-pad connector to the system board.
2. Replace the M2.5 x 5-mm screw and tighten the captive screw.
3. Turn the computer over and replace the thirteen M2.5 x 8-mm screws.
4. Perform steps 2 through 6 in " Removing the Palm Rest " in reverse order.
Back to Contents Page
1 captive screw
2 M2.5 x 5-mm screw (1)
1 palm rest
2 touch-pad connector
