Power supply dc connector pin assignments – Dell Dimension 4700 User Manual
Page 46
Power Supply DC Connector Pin Assignments
The 305-W power supply can operate from an AC power source of 115 VAC or 230 VAC at 50 - 60 Hz. The power supply provides the DC operating voltages
and currents listed in the following table.
Output Voltage
Minimum Current (A)
Maximum Current (A)
1
+5 VDC
0.3
22.0
+3.3 VDC
0.3
2
17.0
