Dell Inspiron 1420 (Mid 2007) - Manual (Page 152)

152
Adding and Replacing Parts
Flash Cache Module
The Flash Cache Module (FCM), is an internal flash drive that helps improve
the performance of your computer.
NOTE:
This card is only compatible with the Windows Vista™ operating system.
NOTE: If you ordered a FCM with your computer, the card is already
installed .
NOTE:
WWAN card and FCM share the same slot. You can install only one card at
a time.
Removing the FCM
1 Follow the procedures in "Before You Begin" on page 129.
2 Remove the hinge cover (see "Hinge Cover" on page 135).
3 Remove the keyboard (see "Keyboard" on page 137).
4 Ground yourself by touching one of the metal connectors on the back of
the computer.
NOTE:
If you leave the area, ground yourself again when you return to the
computer.
5 Remove the screw securing the FCM to the system board.
6 Lift the card out of its connector.
