Dell Latitude XT2 (Early 2009) - Manual (Page 16)

Interface speed 9600–115,200 bps
EMV level Level 1 certified
WHQL certification PC/SC
Compatibility Compatible within a PKI environment
Insert/eject cycles Certified for up to 100,000 cycles
Ports and Connectors
Audio microphone connector, stereo headphone/speakers
connector
IEEE 1394 4-pin serial connector
E-dock Standard E-Dock connector for devices such as E-
Dock advanced port replicators and expansion
stations
The optional media base can be connected to the E-
Dock connector.
Mini-card One dedicated half-mini-card slot for WLAN
One dedicated full-mini-card slot for WWAN / GPS
(mobile broadband)
Network adapter RJ-45 port
USB two 4-pin USB 2.0-compliant connectors
Powered USB 5-pin power supply and 4-pin USB
2.0-compliant connector
USB Two 4-pin USB 2.0-compliant connectors
One USB connector can be used as an eSATA
connector. The other USB connector with PowerShare
can be used to charge a USB device when the
computer is turned on or off.
Video 15-hole connector
Communications
Network adapter 10 / 100 / 1000 Ethernet LAN on system board
Wireless internal WLAN, WWAN, and Bluetooth® wireless
support (if optional cards are purchased)
Video
Video type integrated
Video controller Mobile Intel® GMA X4500 Graphics Controller
Data bus integrated
Video memory up to 256 MB shared memory
Audio
Audio type two-channel high definition audio codec
Audio controller IDT 92HD71B
Stereo conversion 24-bit (analog-to-digital and digital-to-analog)
Interfaces:
Internal high definition audio
External microphone-in connector, stereo
headphones/speakers mini-connector
Speaker one 4-ohm speaker
Internal speaker amplifier 2-Watt channel into 4 ohms
Volume controls Volume control buttons and program menus
Display
Type (active-matrix TFT)
Active X / Y 12.1 inches WXGA
Dimensions
Height 261.12 mm (10.28 inches)
Width 163.2 mm (6.43 inches)
Diagonal 307.34 mm (12.1 inches)
