Table 1-51. Configuration ID = 03h, SOL
Attribute
ID Size Description
R/W
SOL Idle
Timeout
1
2
• Byte[1:2]: Define the inactivity timeout in
minutes, 1-based, LSByte first. This parameter
only applies to the IPMI over LAN session with
SOL payload activated.
• 0h: Session does not timeout and close due to
inactivity. Default value is 01h.
R/W
Telnet/SSH
Redirect Enable
2
1
• 0h: Disable
• 1h: SOL Enabled
• 2h: SMASH Enabled
• Others: Reserved
R/W
Table 1-52. Configuration ID = 04h, Security
Attribute
ID Size Description
R/W
Service Disabled 1
1
Disable or enable services. This attribute takes
precedence over the individual feature
enabled/disabled. Once one service has been
disabled, the BMC will not allow user to enable
the corresponding feature and D5h completion
code must be returned. For example, if
HTTP/HTTPS is disabled, user must not allow
enabling the Web Server through Web Server
Configuration (Configuration ID 0Ch). In other
words, Web can only be disabled or enabled when
HTTP/HTTPS is enabled. Default value is 38h.
• [0] - All service except IPMI are disabled. This
bit takes precedence over other bits. Default is 0.
• [1] - KVM/Virtual Storage, enabled by default.
• [2] - HTTP/HTTPS, enabled by default.
• [3] - SSH, disabled by default.
• [4] - SNMP v2c agent, disabled by default.
• [5] - Telnet, disabled by default.
• [6] - SMASH, disabled by default.
R/W
