Serial Over LAN
The Serial over LAN menu enables users with administrator and operator
privileges to configure the Serial over LAN settings, select or change pertinent
values for each attribute and save any changes.
Table 1-24. Serial Over LAN Settings
Items Description
Enable Serial Over LAN
Checkbox
Enables or disables Serial over LAN (SOL) connection.
Baud Rate Select the IPMI SOL baud rate.
• 19.2 kbps
• 38.4 kbps
• 57.6 kbps
• 115.2 kbps
Channel Privilege Level
Limit
Specify a privilege level on the LAN channel.
Apply Changes Button Use this button to apply the changes.
