Cisco 10008 Router Performance Routing Engine 3 Installation
OL-8544-01
Product Overview
Alphanumeric Display
The alphanumeric display on the front panel provides information on the state of the PRE3. The display
consists of two four-character LED panels.
Table 2 describes the most common messages. If you report
a problem to Cisco, it is helpful to include the message on the PRE3 alphanumeric display in your
problem report.
CompactFlash Disk0 Green Disk0 is active.
STATUS Flashing
Yellow System is booting.
Green PRE3 is active.
Flashing
Green PRE3 is standby.
Off No power to PRE3.
FAIL Yellow A major failure has disabled the PRE3.
Off The PRE3 is operating correctly.
BITS n/a Not supported.
Table 1 PRE3 LED Status and Button Descriptions (continued)
LEDs and Button Status Description
Table 2 Messages on PRE3 Alphanumeric Display
Message PRE3 Status
1111, 2222, 3333, 4444, 5555, 6666,
7777 The PRE3 has just been powered on and is running its
power-on self-test.
ROM DONE The PRE3 has loaded the ROM monitor. This message
appears briefly if the system is configured to boot a Cisco
IOS software image. If the system is not configured to
boot Cisco IOS, this message remains on the display and
the rommon> prompt appears on the terminal window.
AUTO BOOT The ROM monitor is preparing to boot a Cisco IOS image.
BOOT IMGE A Cisco IOS image is starting to boot.
IOS STRT, IOS EXC, IOS FPGA, IOS
FPOK, IOS FILE, IOS STBY, IOS INTF,
IOS MEM, IOS DRVR, IOS LIB, IOS
MGMT, IOS PROT, IOS CONF These messages appear in quick succession during the
boot process.
IOS RUN [On the primary PRE3] The PRE3 has finished booting
and is running Cisco IOS. This is the normal operating
status for the primary PRE.
IOS STBY [On the secondary PRE3] The PRE3 is in standby mode
and ready to take over if the primary PRE3 fails. This is
the normal operating status for the secondary PRE3.
