Cisco 10008 Router Performance Routing Engine 3 Installation
OL-8544-01
Analyzing and Troubleshooting Packets
packets bytes
generic 0 0
mpls_no_eos 0 0
fib_zero_dest 0 0
fib_drop_null 0 0
fib_icmp_no_adj 0 0
fib_icmp_bcast_dst 0 0
mfib_ttl_0 0 0
mfib_disabled 0 0
mfib_rpf_failed 0 0
mfib_null_oif 0 0
tfib_rp_flag 0 0
tfib_eos_violation 0 0
tfib_nonip_expose 0 0
tfib_label_invalid 0 0
tfib_path_unknown 0 0
tfib_nonip_ttl_exp 0 0
icmp_unrch_interval 0 0 /*no ICMP packets created*/
icmp_on_icmp 0 0
icmp_bad_hdr 0 0
icmp_multicast 0 0
icmp_frag 0 0
macr_bad_tag_num 0 0
.
.
.
The following example output indicates the count of the icmp_unrch_interval counter after sending the
100 packets. Notice that the icmp_unrch_interval count now indicates 100 due to the dropped packets.
Router# show pxf cpu statistics drop
FP drop statistics
packets bytes
generic 0 0
mpls_no_eos 0 0
fib_zero_dest 0 0
fib_drop_null 0 0
fib_icmp_no_adj 0 0
fib_icmp_bcast_dst 0 0
mfib_ttl_0 0 0
mfib_disabled 0 0
mfib_rpf_failed 0 0
mfib_null_oif 0 0
tfib_rp_flag 0 0
tfib_eos_violation 0 0
tfib_nonip_expose 0 0
tfib_label_invalid 0 0
tfib_path_unknown 0 0
tfib_nonip_ttl_exp 0 0
icmp_unrch_interval 100 12276 /*incremented by 100*/
icmp_on_icmp 0 0
icmp_bad_hdr 0 0
icmp_multicast 0 0
icmp_frag 0 0
macr_bad_tag_num 0 0
.
.
.
