1-12 Dell Inspiron 3000 Series Service Manual
12.1-Inch Display (continued)
Operating angle 0
°
(closed) to 180
°
Dot pitch 0.264 mm
Power consumption 2.35 W
Controls brightness can be controlled through key
combinations
13.3-Inch Display
Type (M233XT, M266XT,
D233XT, D266XT)
active-matrix color (TFT)
Dimensions:
Height 203 mm (8.0 inches)
Width 271 mm (10.7 inches)
Diagonal 338 mm (13.3 inches)
Maximum resolution 1024 x 768 pixels; 64,000 colors
Response time (typical) 30 ms
Operating angle 0
°
(closed) to 170
°
Dot pitch 0.264 mm
Power consumption 3.9 W
Controls brightness can be controlled through key
combinations
Keyboard
Number of keys 87 (U.S. and Canada); 88 (Europe); 88 (Japan)
Key travel 3.0
±
0.5 mm (0.12
±
0.02 inch)
Key spacing 19.1 mm (0.75 inch)
Layout QWERTY/AZERTY/Kanji
Touch Pad
Interface PS/2-compatible
X/Y position resolutions
(graphics table mode)
20 points/mm (500 points/inch)
Table 1-2. Technical Specifications (continued)
