Dell Latitude D830 (Early 2007) - Manual (Page 17)

10. From the back of the computer, remove the two M2.5 x 5-mm screws.
11. Turn the computer top-side up and open the display.
12. Lift the display assembly out of the computer base.
Removing the Display Bezel
1. Follow the procedures in Before You Begin .
2. Remove the display assembly (see Removing the Display Assembly ).
3. Remove the six rubber display bumpers and two mylar screw covers from around the display bezel.
4. Remove the eight M2.5 x 4.2 x 5-mm shoulder screws from around the display bezel.
1 M2.5 x 5-mm screws labeled "D" (2)
1 M2.5 x 5-mm screws (2)
CAUTION: Before performing the following procedures, follow the safety instructions in the Product Information Guide.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching a connector on the back
panel of the computer.
1 screw covers/display bumpers (8) 2 display bezel
