Dell Inspiron 1526 (Late 2007) - Manual (Page 30)

30
About Your Computer
Bottom View
BATTERY — When a battery is installed, you can use the computer without
connecting the computer to an electrical outlet (see "Using a Battery" on page 45).
BATTERY RELEASE LATCH — Releases the battery (see "Replacing the Battery" on
page 49 for instructions).
P ROCESSOR / MEMORY MODULE / MINI - CARD COMPARTMENT — Compartment that
contains the memory modules, WLAN, WWAN, Ultra Wideband (UWB) cards or
Flash Cache Module (FCM) (see "Wireless Mini-Cards" on page 147).
H ARD D RIVE — Stores software and data.
OPTICAL DRIVE — For more information about the optical drive, see "Using
Multimedia" on page 51.
1 battery 2 battery release latch
3 processor/memory module/mini-card compartment 4 hard drive
5 optical drive
2 3
4
5
1
