Replacing the Processor
Cooling Assembly
WARNING: Before working inside your computer, read the
safety information that shipped with your computer and
follow the steps in Before Working Inside Your Computer .
After working inside your computer, follow the instructions
in After Working Inside Your Computer . For more safety best
practices, see the Regulatory Compliance home page at
dell.com/regulatory_compliance.
Procedure
CAUTION: Incorrect alignment of the processor liquid-
cooling assembly can damage the system board and
processor.
1 Align the screw holes on the processor liquid-cooling assembly with the
screw holes on the chassis.
2 Replace the screws that secure the processor liquid-cooling assembly to
the chassis.
NOTE: The original thermal grease can be reused if the original
processor and processor liquid-cooling are reinstalled together. If
either the processor or the processor liquid-cooling is replaced, use
the thermal grease provided in the kit to ensure that thermal
conductivity is achieved.
3 Apply thermal grease between the processor liquid-cooling assembly and
the processor.
4 In sequential order as indicated on the processor cooling-assembly,
tighten the captive screws that secure the processor liquid-cooling
assembly to the system board.
5 Connect the processor liquid-cooling assembly fan and the processor
liquid-cooling assembly pump-fan cable to the connectors on the system
board.
