Replacing the Logo Board
WARNING: Before working inside your computer, read the
safety information that shipped with your computer and
follow the steps in Before Working Inside Your Computer .
After working inside your computer, follow the instructions
in After Working Inside Your Computer . For more safety best
practices, see the Regulatory Compliance home page at
dell.com/regulatory_compliance.
Procedure
1 Align the screw holes on the logo board to the screw holes on the bracket
and slide the logo board in.
2 Replace the screws that secure the logo board to the bracket.
3 Slide the logo board inside the chassis.
4 Replace the screw that secure the logo board to the bracket.
5 Route and connect the cables that you removed from the connectors on
the logo board.
Post-requisites
1 Replace both the left and right side-panels. See “ Replacing the Side
Panels ”.
2 Replace the stability foot .
