7

PCI-Express x16 slot (SLOT3)

8

M.2 connector (wireless card)

9

coin-cell battery socket (BAT1)

10

CMOS reset jumper (CLEAR
CMOS1)

11

PCI-Express x4 slot (SLOT4)

12

Thunderbolt connector (TBT1)

13

PCI-Express x16 slot (SLOT5)

14

Serial Peripheral Interface
connector (SP11)

15

PCI-fan connector (SIDE_FAN1)

16

drive-bay heat-sensor
connector (SENSOR1)

17

chassis heat-sensor connector
(SENSOR2)

18

PCI-Express power connector
(PCIE_PWR1)

19

PCI-Express fan 1 connector
(PCI_FAN1)

20

SATA drive connectors

21

USB connector (USB1)

22

LED Power Switch (PANEL1)

23

USB connector (USB3_MB1)

24

Advanced Technology xTended
(ATX) power connector (ATX
PWR1)

25

processor socket (CPU1)

26

memory-module slot (DIMM3)

27

memory-module slot (DIMM4)

28

processor liquid-cooling
assembly fan connector
(MID_FAN1)

29

memory fan connector
(TOP_FAN1)

30

processor-power connector
(CPU PWR1)

31

processor liquid-cooling assembly
pump-fan connector
(PUMP_FAN1)

32

memory-module slot (DIMM2)

33

memory-module slot (DIMM1)

I/O Board Components

NOTE: The location of the connectors may vary based on the selections
you made at the time of purchase.
