13. Lift and remove the display assembly from the computer base.
Replacing the Display Assembly
1. Place the display assembly in position and replace the two screws that secure the display assembly to the computer base.
2. Connect the display cable to the system board connector.
3. Route the Mini-Card cables and connect them to the Mini-Cards, if applicable (see Replacing the Mini-Card ).
4. Connect the TV tuner card cables to its connectors.
5. Replace the 3-in-1 Media Card Reader (see Replacing the Media Card Reader ).
6. Replace the palm rest bracket (see Replacing the Palm Rest Bracket ).
7. Replace the hard drive (see Replacing the Hard Drive ).
8. Replace the palm rest (see Replacing the Palm Rest ).
9. Replace the keyboard (see Replacing the Keyboard ).
10. Replace the battery (see Replacing the Battery ).
Back to Contents Page
1 screws (2) 2 display assembly
