10. Lift the 2-in-1 memory and processor board out of its system board connector.
Replacing the 2-in-1 Memory and Processor Board
1. Align the notch in the 2-in-1 memory and processor edge connector with the tab in the connector slot.
2. Slide the 2-in-1 memory and processor board firmly into the slot at a 45- degree angle, and gently press the 2-in-1 memory and processor board down
until it clicks into place. If you do not hear the click, remove the board and reinstall it.
3. Replace the processor system board cover on the 2-in-1 memory and processor board.
4. Replace the four screws that secure the processor system board cover and the 2-in-1 memory and processor board to the system board.
5. Replace the palm rest bracket (see Replacing the Palm Rest Bracket ).
6. Replace the hard drive (see Replacing the Hard Drive ).
7. Replace the palm rest (see Replacing the Palm Rest ).
8. Replace the keyboard (see Replacing the Keyboard ).
9. Replace the battery (see Replacing the Battery ).
10. Update the BIOS (see Flashing the BIOS ).
Back to Contents Page
1 securing clips
CAUTION: Before turning on the computer, replace all screws and ensure that no stray screws remain inside the computer. Failure to do so may
result in damage to the computer.
