ENG-39 ENG-38
ENG
Spare accessories
Maintenance
Perform the daily care according to the following instructions.
• Regularly check that the positions of the magnets and sensors are correct, and they
are secured firmly.
• When the computer, and speed/cadence are dirty, wash them with water or wipe them
with a soft cloth dampened with diluted neutral detergent, then wipe with dry cloth.
Do not use solvents such as benzine or rubbing alcohol as they may damage the sur-
faces.
Specifications
Upper display Current speed 0.0 (4.0) − 150.0 km/h [0.0 (3.0) − 93.0 mph]
For 27-inch tire size
Average speed 0.0 - 150.0 km/h [0.0 - 93.0 mph]
Maximum speed 0.0 (4.0) − 150.0 km/h [0.0 (3.0) − 93.0 mph]
Middle display Cadence 0 (20) − 199 rpm
Average cadence 0 − 199 rpm
Maximum cadence 0 (20) − 199 rpm
Lower display Date ‘07.01.01 − '99.12.31(Display format can be switched)
Clock 0:00’00” − 23:59’59”
[AM 1:00’00” − PM 12:59’59”]
(Both 12 and 24-hour modes can be selected)
Total time 0 − 99999 hour
Odometer 0.0 − 9999.9/10000 − 999999 km [mile]
Elapsed time 00’00”0 − 59’59”9 / 1:00’00” − 99:59’59”
Trip distance 0.00 − 9999.99 km [mile]
Countdown distance 9999.90 − 0.00 km [mile]
Lap number L-01 − L-99
Average lap speed in real time 0.0 − 150.0 km/h [0.0 − 93.0 mph]
Lap timer 00’00”0 − 59’59”9 / 01:00’00” − 99:59’59”
Trip lap distance in real time 0.00 − 9999.99 km [mile]
Lap Upper display (average lap speed,maximum lap speed)
Middle display (average lap cadence,Lap number,maximum lap cadence)
Lower display (trip lap distance,lap time,split time)
Control system 4-bit one-chip microcomputer, crystal oscillator
Display system Liquid crystal display (EL backlight)
Speed/Cadence sensor signal detection system Noncontact magnetic sensor
Sensor signal transmission and reception 2.4 GHz ISM Band
Communication range 5 m (above 5 m, transmission distance may vary due to environmental conditions)
Operating temperature range 32 °F − 104 °F [0 °C − 40 °C]
(This product will not function appropriately when exceeding the
Working Temperature range. Slow response or black LCD at lower
or higher temperature may happen respectively.)
Storage temperature range -4 °F − 122 °F [-20 °C − 50 °C]
Wheel circumference set range 0100 − 3999 mm
Power supply/battery life Computer : CR2032 x 1 / Approx. 1 years (When using 1 hour/day)
Speed sensor : CR2032 x 1 / Approx. 1 years (When using 1 hour/day)
Dimensions/Weight Computer : 2-7/32” x 1-1/2” x 11/16” (56.0 x 38.0 x 17.3 mm) / 0.98 oz (28 g)
(With the batteries)
Speed sensor : 2-9/16” x 3-9/16” x 9/16” (65.0 x 90.5 x 14.4 mm) / 1.25 oz (36 g)
(With the batteries)
* When the elapsed time exceeds 100 hours, or the trip distance exceeds 9999.99 km/h, “E” appears in place of
the average speed.
* Designs and specifications are subject to change without notice, due to modifications or improvements.
Display
functions
Standard accessories
#160-2380
Parts kit #160-2385
Speed sensor kit #160-0280
Bracket band
#160-2193
Bracket #169-9691
Wheel magnet #169-9766
Cadence magnet
#166-5150
Lithium battery (CR2032)
