Always charge the product before use.

USB cable

To PC or USB battery charger

1

2

HL-EL150RC

Manual

RECHARGEABLE HEADLIGHT

Charging

Charging is completed

Standard

charging time

Approx.

3 h

(USB 2.0)

PRECAUTIONS ON USE

• Before your trip, please make sure the light is

firmly mounted to the bracket, it lights up,

and the light is not blocked by baggage, etc.

• Do not place it within children’ s reach.
• In preparation for unexpected battery shutoff,

we recommend you carry a spare light.

• Mounting the light unit too close to a wireless

computer may adversely affect the reading of

the computer.

• This product is water-resistant under normal

daily use and can be used in the rain.

However, do not intentionally submerge it in

water.

• If the light unit or parts become dirty with mud,

etc., clean with a soft cloth which is moistened

with mild soap. Never apply paint thinner,

benzine or alcohol; damage will result.

PRECAUTIONS ON CHARGING

• We recommend using 500+mA (USB2.0) USB

battery charger.

• When your PC is in sleep state, the unit

cannot be charged.

• Charging and lighting times are approximate

values, and will vary by environmental and

user conditions.

PRECAUTIONS WHEN MOUNTING

• To re-adjust the beam angle, loosen the dial

enough to move the bracket, and firmly

tighten it after adjustment.

• Be sure to tighten the dial by hand. When you

tighten it too hard with a tool, the screw

thread may be stripped.

• Round off the cut edge of the bracket strap to

prevent injury.

HOW TO REPLACE THE BATTERY

When the operating time decreases signifi-

cantly, the battery life is close to an end.

Please contact CatEye local distributor listed on

our website www.cateye.com or CatEye for

replacing battery.

PRECAUTIONS ON DISPOSAL

When disposing of the light unit, remove the

internal rechargeable battery and dispose of it

according to local regulations.

Before using the light, please read
this manual and the attached
“Lithium-ion Batteries” thoroughly,
and keep them for future reference.

ENG

Design Pat. Pending

Copyright© 2014 CATEYE Co., Ltd.
EL15RC-141001

2

LIMITED WARRANTY

2-year Warranty: Light unit only

(excludes battery deterioration)

CatEye products are warranted to be free of defects from materials

and workmanship for a period of 2 years from original purchase. If

the product fails to work during normal use, CatEye will repair or

replace the defect at no charge. Service must be performed by CatEye

or an authorized retailer. To return the product, pack it carefully and

enclose the warranty certificate (proof of purchase) with instruction

for repair. Please write or type your name and address clearly on the

warranty certificate. Insurance, handling and transportation charges

to CatEye shall be borne by person desiring service. For UK and

REPUBLIC OF IRELAND consumers, please return to the place of

purchase. This does not affect your statutory rights.

Please register your CatEye product on the website.

http://www.cateye.com/en/support/regist/

SPARE/OPTIONAL PARTS

HOW TO CHARGE

SWITCH OPERATION

Battery

: Li-ion 3.7v 800 mAH

Temperature range : 14˚F – 104˚F (-10˚C – 40˚C)

Recharge/discharge number of times

: About 300 times (until the rated

capacity drops to 70%)

Dimensions/weight : 1-11/32” x 3-35/64” x 1-3/8”

(34 x 90 x 35 mm) / 2.3 oz (65 g)

* The specifications and design are subject to change

without notice.

1

HOW TO MOUNT

2

3

Switch (Indicator)

Light unit

USB cable
(MICRO USB)

SPECIFICATIONS

FlexTight™ bracket
(H-34N)

Charge jack cover

*1

Bracket

Rubber pad

Dial

Strap

Release

button

Screw

*2

*2

OFF

ON

Hi

Low

Approx.

2 h

Approx.

6 h

Approx.

30 h

Flash

Switch

*2: When you turn the

light on, it lights up

in the last lighting

mode you used.

(Mode memory

function)

* When the switch (indicator) lights up, the remaining battery power is 20% or less.

Please charge as soon as possible.

5338827N

FlexTight™ bracket

(H-34N)

5341831N

Helmet mount

5338890

FlexTight™ bracket

(H-36)

5342730

USB cable (MICRO USB)

*1: Check the dial and screw (*1) on the bracket periodically, and use them without any loosening.

* A flashing light indicates a charging

error. Remove the cable and try again.

Press

and hold

Press and hold

Double-click

Double-click

Click

Click
