Installing Enclosure Components

Figure 3-5. Removing and Installing an EMM

Installing an EMM

1 Carefully insert the EMM into the empty module slot.
2 Push the module to the back of the slot until it is firmly seated in the backplane connector (see

Figure 3-5).

3 Push the release lever in (toward the enclosure) until the module is retracted into the slot and secure.
4 If necessary, update the firmware for your EMM(s). See the Dell Support website at support.dell.com

for the latest information on firmware updates.

NOTE:

If you have two EMMs installed, both must be running the same firmware level. For information on

updating firmware, see "Downloading Firmware."

For information on EMM connections and cabling, see “Operating Your Storage Enclosure.”

release tab

release lever
