Replacing the Memory and Processor Board
1.
Follow the procedures in
Before You Begin
.
2.
Align the notch in the memory and processor board with the tab in the connector.
3.
Slide the memory and processor board firmly into the slot at a 30-degree angle, and press the memory and processor board down until it clicks into
place. If you do not hear the click, remove the memory and processor board and reinstall it.
4.
Replace the four screws that secure the memory and processor board to the system board.
5.
Replace the processor heat sink (see
Replacing the Processor Heat Sink
).
6.
Replace the palm rest bracket (see
Replacing the Palm Rest Bracket
).
7.
Replace the memory module (see
Replacing the Memory Module
).
8.
Replace the hard drive (see
Replacing the Hard Drive
).
9.
Connect the speaker cable to the speaker cable connector on the I/O board (see
Replacing the Speakers
).
10.
Replace the palm rest (see
Replacing the Palm Rest
).
11.
Replace the keyboard (see
Replacing the Keyboard
).
12.
Replace the battery (see
Replacing the Battery
).
Back to Contents Page
CAUTION:
Before turning on the computer, replace all screws and ensure that no stray screws remain inside the computer. Failure to do so may
result in damage to the computer.
