Pasang modul pass-through – Dell POWEREDGE M1000E User Manual
Page 97

Modul Pass-Through FC8PT
97
1. Pasang Modul Pass-Through
CATATAN:
Peralatan komputer mengandung komponen yang peka terhadap listrik
statis yang dapat rusak selama penanganan. Untuk mengantisipasi listrik statis,
pakailah gelang pembumi selama proses pemasangan.
1 Lepas tutup pin dari pin konektor di bagian belakang modul pass-through,
seperti terlihat dalam Gambar 1-1, Melepas Tutup Pin.
Gb: Gambar 1-1. Melepas Tutup Pin
2 Cari slot modul yang masih kosong pada server.
3 Lepas selongsong modul I/O, jika masih terpasang pada slot yang dipilih.
4 Pastikan lengan pengancing ada dalam posisi tidak terkancing, dan
sisipkan modul pass through dengan sempurna.
