130
Installing System Components
6 Install the heat sink.
a Using a clean lint-free cloth, remove the thermal grease from the
heat sink.
b Open the grease packet included with your processor kit and apply
thermal grease evenly to the center of the top of the new processor.
CAUTION:
Using excess thermal grease can cause grease to contact the
processor shield, which can cause contamination of the processor socket.
c Place the heat sink on the processor. See Figure 3-22.
d Using a #2 Phillips screwdriver, tighten the heat-sink retention
screws. See Figure 3-22.
7 Replace the system board shroud. See "Installing the System Board
Shroud" on page 106.
8 Close the system. See "Closing the System" on page 83.
9 Reconnect the system to its electrical outlet and turn the system on,
including any attached peripherals.
10 Press to enter the System Setup program, and check that the processor
information matches the new system configuration. See "Entering the
System Setup Program" on page 58.
11 Run the system diagnostics to verify that the new processor operates
correctly.
See "Running the Embedded System Diagnostics" on page 164 for
information about running the diagnostics.
System Battery
Replacing the System Battery
WARNING:
Only trained service technicians are authorized to remove the system
cover and access any of the components inside the system. Before you begin this
procedure, review the safety instructions that came with the system.
WARNING:
There is a danger of a new battery exploding if it is incorrectly
installed. Replace the battery only with the same or equivalent type recommended
by the manufacturer. See your safety information for additional info.
