LOCAL MANAGEMENT
Page 6-10
6.3.2 The Configuration Screen
To access the Configuration screen from the Feature Selection screen,
use the arrow keys to highlight the IP Address Assignment option
then press the Return key or F7. The Configuration screen shown in
Figure 6-5 appears.
Figure 6-5. Configuration Screen
The SEHI Configuration screen lets you assign the IP Address, Subnet
Mask, and Default Gateway. You can also use the Port Enable
Override option to enable all device ports in the stack. This option
overrides the Port Disable setting in the Statistics screen.
The following sections explain each field on the Configuration screen
and instructions on how to change them.
I/F
Gives the number of the interface corresponding to the channels over
which packets with that IP Address are passing. On the SEHI, this
value is always 1.
IP Address
Displays the IP address of the SEHI.
Cabletron SEHI Revision X.XX.XX
CONFIGURATION
SEHI LOCAL MANAGEMENT
SAVE COMMUNITY NAMES TRAP TABLE SNMP TOOLS RETURN
F6 F7 F8 F9
I/F IP Address SubNET Mask MAC Address
1 000.000.000.000 000.000.000.000 00-00-1d-05-dc-36
Default Gateway: 0.0.0.0
Serial Port 1 Application: CONSOLE Baud Rate: 9600 --ACTIVE--
Port Enable Override: OVERRIDE DISABLED
