44
Loading Documents
Observe the following precautions when loading documents into the ADF.
WARNING
• The maximum stack of documents that can be loaded into the ADF at one time is
indicated by the stack mark on the inner side of the paper guide. The ADF can
accommodate up to 20 sheets of 20 lb. bond (80 g/m
2 ) photocopy paper or a stack of
documents no higher than 0.08 inch or 2 mm. Loading stacks higher than this may result
in paper jams.
• Uncurl or straighten any documents that are curled or wrinkled.
○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
1. Place documents face up on the document tray.
Stack Mark
0.08 inch or 2 mm
