Table 6A — Electrical Data (3 Ph/60 Hz)
UNIT
38AKS
UNIT
COMPR
FAN MOTORS (Single Phase)
Model
Volts
MCA
ICF
MOCP
(Fuse
Only)
RLA
LRA
Total
Fans
FLA (ea)
Fan No.
kW
Nameplate
Supplied*
Min
Max
1
2
013
501
208-230
187
253
62.5
178
100
43.6
170
2
4.3
3.7
1.41
201
380
342
418
35.0
101
50
24.0
93
4.3
3.7
601
460
414
528
29.1
81
40
20.0
77
2.3
1.9
101
575
518
660
22.8
67
35
15.7
62
1.8
1.8
014
501
208-230
187
253
69.3
199
100
49.3
191
2
4.3
3.7
1.41
201
380
342
418
38.0
112
60
26.5
104
4.3
3.7
601
460
414
528
31.7
84
50
22.1
80
2.3
1.9
101
575
518
660
25.6
73
40
17.9
69
1.8
1.8
016
501
208-230
187
253
87.5
274
125
63.6
266
2
4.3
3.7
1.41
201
380
342
418
49.3
153
80
36.0
145
4.3
3.7
601
460
414
528
40.7
124
60
29.3
120
2.3
1.9
101
575
518
660
33.0
100
50
23.8
96
1.8
1.8
024
501
208-230
187
254
93.4
353
150
67.9
345
2
4.3
3.7
1.41
201
380
342
418
49.7
199
80
34.6
191
4.3
3.7
601
460
414
508
48.1
177
80
34.7
173
2.3
1.9
101
575
518
632
40.1
124
60
28.8
120
1.8
1.8
LEGEND
FLA
— Full Load Amps (Fan Motors)
ICF
— Maximum Instantaneous Current Flow during start-up
(LRA of compressor plus total FLA of fan motors)
kW
— Total Fan Motor Input (kilowatts)
LRA
— Locked Rotor Amps
MCA
— Minimum Circuit Amps per NEC (U.S.A.),
Section 430-24
MOCP — Maximum Overcurrent Protection (amps)
RLA
— Rated Load Amps (Compressor)
*Units are suitable for use on electrical systems where voltage sup-
plied to the unit terminals is not below or above the listed limits.
NOTES:
1. The MCA and MOCP values are calculated in accordance
with the National Electrical Code (NEC) article 440 (U.S.A.
standard).
2. Motor RLA and LRA values are established in accordance
with Underwriters’ Laboratories (UL) Standard 1995 (U.S.A.
standard).
LEGEND
EQUIP GND — Equipment Ground
NEC
— National Electrical Code
Factory Wiring
Field Wiring
Fig. 7 — Main Power Supply Wiring
LEGEND
C
— Compressor Contactor
HD
— Heating Device
IFC
— Indoor-Fan Contactor
LLSV1 — Liquid Line Solenoid Valve 1 — Refrigerant Migration
Control
LLSV2 — Liquid Line Solenoid Valve 2 — Capacity Control
R
— Relay
Factory Wiring
Field Wiring
NOTES:
1. Combination LLSV plus IFC va should not exceed 30 va.
2. Do not exceed 5 va (24 vac) per coil.
3. If va values shown in Notes 1 and 2 must be exceeded, use
accessory relay transformer package 38AE900001 (60 Hz) or
38AD900003 (50 Hz and 380-3-60).
Fig. 8 — Remote Thermostat Wiring
11
