Char-Broil RED 463250211 User Manual
Page 20
13
20
14
Assembled
warming rack
Place cooking grates onto the firebox as shown. Insert the three wire ends at rear of warming rack into holes in back of
firebox. Front wires of warming rack rest on sides of firebox.
Warming rack
Cooking grate
Place trough into fire box. Align pins at front of trough with the holes at front of fire box.
Trough
Trough pin
