PARTS LIST
NOTE: Some grill parts shown in the assembly steps may differ slightly in appearance from
those on your particular grill model. However, the method of assembly remains the same.
11
Not Pictured:
Key Qty Description
A 1 TOP LID, OUTER
B 1 INNER INSERT F/ TOP LID
C 2 BEZEL, F/ LID HANDLE
D 1 HANDLE F/ TOP LID
E 1 LOGO PLATE, TEMP GAUGE
F 2
RUBBER BUMPER, RECTANGLE, F/ TOP
LID
G 1 FIREBOX
H 2 COOKING GRATE
I 1 WARMING RACK
J 2 MAIN BURNER, F/ FIREBOX
K 2
ELECTRODE W/ WIRE/COLLECTOR, F/
MAIN BURNER
L 1 CARRY OVER, F/ MAIN BURNER
M 2 SIDE SHELF, FIXED
N 2 SIDE SHELF, FOLDING
O 1 FASCIA, F/ LEFT SIDE SHELF
P 1 FASCIA, F/ RIGHT SIDE SHELF
Q 1 MAIN CONTROL PANEL
R 1 HOSE VALVE REGULATOR ASSY
S 1 MATCH HOLDER
T 2 BEZEL, F/ CONTROL KNOB
U 2 CONTROL KNOB
V 1 CART UPPER BACK PANEL
W 1 HEAT SHIELD, F/ TANK
X 1 FRONT DOOR BRACE
Y 1 ELECTRONIC IGNITION MODULE
Z 1
BUTTON, F/ ELECTRONIC IGNITION
MODULE
AA 1 IGNITER SWITCH MODULE
BB 1 DOOR, NO HANDLE
CC 1 DOOR HANDLE
DD 1 CART LEFT SIDE PANEL
EE 1 CART RIGHT SIDE PANEL
FF 1 BOTTOM SHELF
GG 1 TANK SCREW, F/ BOTTOM SHELF
HH 2 CASTER, LOCKING
II 2 CASTER, FIXED
JJ 1 HARDWARE F/ TOP LID ASSEMBLY
KK 2 RUBBER BUMPER, LID
LL 1 TROUGH, FIREBOX
Key Qty Description
… 1 DOOR MAGNET
… 1 BENT U PIN
… 1 HARDWARE PACK
… 1 ASSEMBLY MANUAL, ENGLISH
… 1 ASSEMBLY MANUAL, SPANISH
