HSIM-G01/G09 User’s Guide A-1
APPENDIX A
SPECIFICATIONS
This appendix lists the specifications and regulatory requirements for the
HSIM-G01 and HSIM-G09. Cabletron Systems reserves the right to
change these specifications at any time without notice.
The HSIM-G01 and HSIM-G09 are both fiber optic devices with an SC
connector. The HSIM-G01 supports multimode (MMF) fiber cable, and
the HSIM-G09 supports both multimode and single mode (SMF) fiber
cable, as indicated in
Table A-1 below. To use multimode fiber with the
HSIM-G09, Launch Mode Conditioning cable must be used. Refer to
Section 2.3.2 for details.
A.1 GIGABIT ETHERNET SPECIFICATIONS
The following specifications for the HSIM-G meet the IEEE 802.3z
specifications.
A.1.1 HSIM-G01 Specifications (1000Base-SX)
Table A-1 HSIM-G01 Optical Specifications
62.5 µm MMF 50 µm MMF
Transmit Power
(minimum)
-9.5 dBm -9.5 dBm
Receive Sensitivity -17 dBm -17 dBm
Link Power Budget 7.5 dBm 7.5 dBm
