HSIM-G01/G09 User’s Guide 4-1
CHAPTER 4
LOCAL MANAGEMENT
This chapter provides information on the HSIM-G screens accessible via
the Local Management of the host platform. One Local Management
screen is specific to the HSIM-G, which is detailed in this chapter. All
other screens are detailed in the Local Management manual for the host
platform, and are not covered in this manual. Refer to the host platform’s
manual for detailed information on the other screens.
Make sure that the following requirements have been met before
accessing the HSIM-G through Local Management:
• The HSIM-G is installed in the host platform.
• The host platform is powered up and operational.
• A Local Management terminal is properly configured and connected
to the host interface module or standalone device in which the
HSIM-G resides.
4.1 NAVIGATING LOCAL MANAGEMENT SCREENS
In order to view the specific Local Management screen for the HSIM-G,
you must navigate through a series of Local Management screens via the
host platform.
Figure 4-1 shows a typical hierarchy of screens that you
may have to navigate through in order to reach the HSIM-G screens. The
screen names shown in boldface indicate a typical path you would take.
NOTE
Refer to the host platform user’s guide to establish a Local
Management connection. Refer to
Section 1.5 for details on
accessing host platform manuals.
NOTE
Figure 4-1 is only an example of how the HSIM-G screen may
be accessed. Refer to the host platform documentation for a
detailed definition of the other screens.
