Chapter 4: Local Management
4-2 HSIM-G01/G09 User’s Guide
Figure 4-1 Typical Hierarchy of Local Management Screens
4.2 GIGABIT ETHERNET CONFIGURATION SCREEN
The Gigabit Ethernet Configuration screen allows the user to support the
HSIM-G01 and the HSIM-G09.
The screen (see Figure 4-2 ) displays the type of interface used
(HSIM-G01 or HSIM-G09), the device or module in which the HSIM-G
is installed, and the port number of the module in which it is installed.
The link status, current operating mode, and advertised ability are also
displayed. The screen allows the user to enable or disable
Auto-Negotiation and Advertised Ability.
To access the Gigabit Ethernet Configuration screen, navigate through the
Local Management screens until the Module or Device Specific
Configuration Menu screen displays. Use the arrow keys to highlight the
High Speed Interface Configuration menu item and press ENTER. The
Gigabit Ethernet Configuration screen,
Figure 4-2 , displays.
