LCD Module
The LCD module provides an initial configuration/deployment wizard, as
well as access to infrastructure and blade information and error reporting. See
Figure 1-5.
Figure 1-5.
LCD Module
1
LCD screen
2
scroll buttons (4)
3
selection ("check") button
1
2
3
