Installation Guide
21
Installing the Side Stabilizer Feet
1 Remove the side panel.
2 On the side of the rack frame’s bottom rail, locate the four holes
(see Figure 1-12).
3 Position each stabilizer foot against the base of the rack frame and align
its holes with the corresponding holes in the frame.
Figure 1-12. Installing the Side Stabilizer Feet
4 Use the provided bolts, washers, and cage nuts to secure each foot
to the rack as shown in Figure 1-12.
1 side stabilizer foot (2 per side)
