920 series, Pressure relief and surge anticipator valve, Model – Ames Fire & Waterworks 925GS Stainless Steel Pressure Relief and Surge Anticipator Control Valve User Manual
Page 2
01/06
920 Series
Model
8550 Hansen Road
•
Houston, Texas 77075
•
(Ph) 713.943.0688
•
(Fx) 713.944.9445
•
www.amesfirewater.com
Installation Guidelines
• Prior to installation, flush line to remove debris.
• Install valve horizontally “in line” (cover facing up), so flow arrow matches flow through the line. Avoid
installing valves 6” and larger vertically. Consult factory prior to ordering if installation is other than
described.
• Install upstream and outlet isolation valves. NOTE: When using butterfly valves, insure disc does not
contact control valve. Damage or improper valve seating may occur.
• Provide adequate clearance for valve servicing and maintenance.
• Install pressure gauge to monitor discharge header pressure.
• Connect sensing line to main discharge header using 3/4” diameter minimum tubing / piping.
Other AMES Pressure Relief / Backpressure or Sustaining Control Valves
920 / 620
Pressure Relief / Backpressure or Sustaining Valve
920-01 / 620-01
Backpressure / Sustaining Valve with Hydraulic Check Feature
920-01-15 / 620-01-15
Pressure Sustaining Valve with Solenoid (On-Off) and Check Feature
920-15 / 620-15
Pressure Sustaining Valve with Solenoid (On-Off) Feature
PRESSURE RELIEF and
SURGE ANTICIPATOR VALVE
925
625
