Parts – Ames Fire & Waterworks M300Na Stainless Steel Double Check Detector Assemblies with Bi-Link Check Valves for High Flow Fire Systems User Manual
Page 3
3
6. Closure Sleeve Test Cock with O-ring
7. Closure Sleeve
5. E-clip and Clevis Pin
4. Elastomer Shutoff Disc
2. Second Check Module
8. Sleeve O-ring
3. Check Module O-ring
1. First Check Module
For repair kits and parts, refer to our Backflow Pre-
vention Products Repair Kits & Service Parts price list
PL-A-RP-BPD found on
www.amesfirewater.com.
Parts
