Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box
Description
24 — Not used
101 40A** Anti-lock Brake System (ABS)
module or IVD Module
102 40A** ABS module or IVD module
103 40A** SSP4 Relay, SSP4 Relay (coil)
104 30A** Left-hand power seat motors,
Left-hand power lumbar motor,
Driver seat memory module
105 30A** Starter motor solenoid, Ignition
switch
106 30A** Delayed accessory relay, Delayed
accessory relay coil, FEM- right-hand
front window motor
107 50A** Engine cooling fan motors, Cooling
fan dropping resistor
108 — Not used
109 30A** Heated seat modules
110 50A** Right-hand Power Sliding Door
(PSD) module
111 40A** Fuse junction box
112 — Trailer tow - electric brake controller
(customer access)
113 30A** FEM - left-hand window motor
114 40A** SSP3 relay, SSP3 relay coil
115 50A** Fuse junction box bus #2
116 30A** Heated backlight relay
117 40A** Auxiliary blower relay coil, Auxiliary
blower motor
118 50A** Left-hand PSD module
119 30A** Fuse junction box bus #1
120 40A** Front blower relay coil, Front blower
motor
2003 Windstar (win)
Owners Guide (post-2002-fmt)
USA English (fus)
Roadside Emergencies
162
