Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse
Panel Description
19 10A Starter interrupt relay (coil)
20 — Not used
21 — Not used
22 10A Heated Mirrors
23 20A Body power point, Auxiliary
blower relay #1 and #2 coils
24 — Not used
25 10A Radio (Anti-theft)
26 10A Air bag module, Passenger air bag
deactivated indicator, Passenger
seat weight pressure sensor ECU
27 — Not used
28 10A Cluster
29 2A Speed control deactivation switch
Relay 1 — Switched system power relay #4
Relay 2 — Accessory delay relay
Relay 3 — Front blower motor relay
Relay 4 — Switched system power relay #3
Relay 5 — Rear defrost relay
Relay 6 — Auxiliary blower motor relay
Power distribution box
The power distribution box is located in the engine compartment. The
power distribution box contains high-current fuses that protect your
vehicle’s main electrical systems from overloads.
Always disconnect the battery before servicing high current
fuses.
Always replace the cover to the power distribution box before
reconnecting the battery or refilling fluid reservoirs
If the battery has been disconnected and reconnected, refer to the
Battery section of the Maintenance and specifications chapter.
