FORD 2003 Windstar v.3 - Manual (Page 161)

Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box
Description
10 15A* Right front park lamp, Right front
turn lamp, Right front cornering
lamp, Right front auxiliary driving
lamp
11 15A* Left front park lamp, Left front turn
lamp, Left front cornering lamp, Left
front auxiliary driving lamp
12 15A* Left headlamp (low and high beam)
13 10A* Alternator field sense
14 10A* FEM (left door lock motor)
15 20A* Trailer tow park lamps
16 20A* Trailer tow turn lamps
17 — Not used
18 — Not used
19 15A* AX4S transaxle, Vapor Management
Valve (VMV), A/C clutch relay coil,
EGR control solenoid, Engine fuel
control HO2S #11 sensor, Engine fuel
control HO2S #21 sensor, Catalyst
monitor HO2S #12 sensor, Catalyst
monitor HO2S #22 Sensor, Canister
vent solenoid, Intake manifold runner
control
20 15A* Ignition coil, Intake Air Control (IAC)
valve, Fuel injectors, Mass Air Flow
(MAF) sensor, Fuel pump relay coil,
Intake manifold runner control,
High-speed cooling fan relay coil,
Low-speed cooling fan relay coil,
PCM, Passive anti-theft receiver
21 — Not used
22 — Not used
23 — Not used
2003 Windstar (win)
Owners Guide (post-2002-fmt)
USA English (fus)
Roadside Emergencies
161
