Fuse/Relay

Location

Fuse Amp

Rating

Passenger Compartment Fuse

Panel Description

10

15A

Heated backlite relay (coil),
Speed control module, Anti-lock
Brake System (ABS) module or
IVD Module, Heated seat switch
(if equipped), Heated seat module
(if equipped), Cluster, Front temp
blend door actuator, Brake shift
interlock solenoid, PCM, PSD
module, Reverse Sensing System
(RSS), Front A/C control head,
Steering wheel angle sensor (if
equipped)

11

15A

Electric brake controller, Brake
shift interlock solenoid, Rear
electronic module

12

20A

Center high-mounted stop lamp

13

10A

Right rear turn lamp, Left stop
lamp, Left rear park lamp

14

10A

Autolamp sensor, Transmission
overdrive cancel switch, Front
electronic module, Compass
module, Electrochromatic mirror,
PSD overhead console switch

15

20A

Console power point

16

10A

Cluster

17

20A

Cigar lighter/Powerpoint, Datalink
connector

18

15A

Quarter Window Motors, RH
window switch backlighting, RH
lock switch backlighting, Master
control switch (LH) backlighting,
Radio, VCP, Liquid Crystal Display
(LCD), Front electronic module
