• Refer to the instructions included with towing accessories for the

proper installation and adjustment specifications.

Engine

Maximum GCWR - kg

(lbs.)

Trailer weight range (0

- maximum) - kg (lbs.)

Van/Wagon

3.8L without

Trailer Tow

package

3175 (7000)

0-907 (0-2000)

Wagon

3.8L with

Trailer Tow

Package

3856 (8500)

0-1588 (0-3500)

Vehicle towing capability/Trailer hitch

requirement

Trailer Weight

range

Model/Engine

GCWR - kg
(lbs)

Hitch type
required

Van/3.8L,
Wagon/3.8L

3175 (7000)

Class I
non-equalizing
weight carrying

0–907 (0–2000)

Wagon/4.2L

3266 (7200)

Wagon/3.8L with
Trailer Tow
option

3856 (8500)

Class I
non-equalizing
weight carrying

0–907 (0–2000)

Wagon/3.8L with
Trailer Tow
option

3856 (8500)

Class II
equalizing
weight
distributing

0–1588 (0–3500)

Wagon/4.2L with
Trailer Tow
option

3946 (8700)

Class II
equalizing
weight
distributing

0–1588 (0–3500)

Do not exceed the maximum loads listed on the Safety Compliance
Certification label. For load specification terms found on the label, refer
to Vehicle loading in this chapter. Remember to figure in the tongue
load of your loaded trailer when figuring the total weight.
