Protected components Fuse amp rating Fuse/relay number
Powertrain control module - vehicle power
1
20A 1
7
Powertrain control module - vehicle power
2
20A 1
8
Powertrain control module relay - 9
Power point 1 - driver front
20A 3
10
Powertrain control module - vehicle power
4
15A 2
11
Powertrain control module - vehicle power
3
15A 2
12
Powertrain control module - vehicle power
5
10A 2
13
Powertrain control module - vehicle power
6
10A 2
14
Run/start relay - 15
Power point 2 - console
20A 3
16
Transmission oil (Fusion Energi)
20A 3
17
Powertrain control module - keep alive
power
10A 1
18
Electronic power assist steering
10A 1
19
Run/start lighting
10A 1
20
Inverter system (Hybrid)
15A 1
21
Not used - 22
Blind spot information system, Rear view
camera, Adaptive cruise control, Heads-up
display
15A 1
23
Transmission oil (Fusion Energi)
10A 1
24
Anti-lock brake system
10A 2
25
Powertrain control module
10A 2
26
241
Fuses
