Adjustments
Backpost Adjustment
The angle and depth of the backposts may be
adjusted by repositioning the backpost pivot
plate in the pre-drilled holes on the frame.
Flip Arm / Locking Arm
To adjust height of armrests, loosen and
remove the bolts and nuts holding the arm to
the backpost tube. Align holes in arm with
holes in backpost tube at desired height.
Reassemble with bolts and nuts.
“T” Arm
To adjust the height of the “T” arm, rotate lever
outward. Lift or lower arm pad to desired
height and rotate lever back to forward
position to lock in place.
