Gizmo
33
Main Frame
continued…..
Wheel lock Options
The Gizmo also offers wheel lock options of:
rear mount pull to lock, rear mount push to
lock, wheel lock extensions and hub locks.
Hub Lock*
1. To lock the wheels, push the Hub Lock
lever (as shown). This will lock the wheels
in place.
2. To unlock the wheel, pull the Hub Lock
lever. This will unlock the wheels and al-
low them to roll.
*Patent Pending
Folding Back
The Gizmo come standard with a folding back.
1. To fold the back down, pull upward on the
trigger while pushing backposts forward
toward seat.
2. To place the backpost to the upright
position, pull backposts up until trigger
snaps into place.
Note: The backposts fold down completely
when using a solid seat and back. When using
a sling seat and back the backposts will only
fold partially.
lock
unlock
