Freedom Designs Gizmo Tilt in Space - Manual (Page 22)

Freedom Designs, Inc.
20
For ease of transporting and lifting, the Gizmo can be
easily unfolded and folded.
Always engage the wheel locks by pushing forward or
pulling back on the levers before unfolding the chair.
(see pages 32-33).
1. Unfolding is accomplished by applying even
downward pressure on the cross braces. The
cross braces will lock into place.
2. Grasp the push handles and pull them to an
upright position where they will lock into place.
3. Push the flip back armrests down to the flat
position or insert optional T-arm into receiver
socket until it snaps into place.
Note: The cross braces need to be opened to their
maximum
point where the stops rest in the
notches of the cross brace and lock into place .
Unfolding the
Gizmo
