Gizmo
29
Main Frame
continued…..
Angle Adjustable Footboard…….
2. To remove the footboard for transfer,
unscrew the knob assemblies underneath
the receivers. Lift the footboard upward,
out of the receivers.
3. To attach the footboard after transfer,
align the footboard fittings into the
receivers. Turn the knobs on each side to
tighten.
4. To change the angle of the footboard, use
an allen wrench and loosen the flat head
screws on the top of the footboard. When
the desired angle or depth is reached,
tighten both screws.
