Freedom Designs, Inc.
28
Flip-up Individual Aluminum Footplates
with Angle Adjustment
Angle Adjustable Footboard
1. To attach the footboard to the frame, place the
footboard clamps on the frame. Set the clamps at
the desired height. Insert the receiver into the
clamps and tighten the 2 hex head screws on
each side.
Main Frame
continued…..
