Freedom Designs Gizmo Tilt in Space - Manual (Page 28)

Freedom Designs, Inc.
26
Main Frame
continued…..
Pop-Up Removable Hangers
The Gizmo frames my be shipped with optional pop-up
hangers in 75° or 90°.
1. To remove the hanger, place your hand on the
hanger release lever.
2. Pull back on the lever towards the chair. This will
enable the hanger to pop-up and swing away for
ease of transfer.
3. To remove the hanger, lift the hanger upward until
the pivot saddle is out of it’s receiver on the frame.
4. To attach the hanger, line up the pivot saddle with
it’s receiver on the frame and insert downward
pressure until hanger locks into place.
75° Hanger
90° Hanger
