Installation Instructions for
Reflection
904-REFLEC-32-F1-02
1718 W. Fullerton Ave
Chicago, IL 60614
Tel: 773-770-1195
Fax: 773-935-5613
www.edgelighting.com
Install the Mounting Plate
1
REFLEC-32-F1-_
© 2012 Edge Lighting. All Rights Reserved.
A
1: Align the mounting plate center hole with the electrical box.
Level the mounting plate horizontally and mark the six
mounting plate holes onto the wall.
MOUNTING HOLE
SAVE THESE INSTRUCTIONS!
- This product is ETL listed for indoor dry locations.
- This product is wall mounted only.
- This product can mount to either a 4" square electrical box
with round plaster ring or an octagon electrical box.
- This instruction shows a typical installation
- This product is not dimmable.
IMPORTANT INFORMATION
B
WALL
3
ANCHOR
3: Use a 9/32 drill bit to make holes on all six marked points.
4: Tap the anchors into the drilled holes with a hammer.
9/32 DRILL BIT
4
4
MOUNTING PLATE
NOTE: It is recommended that one person holds the mounting
plate while the electrician installs it.
NOTE: Make sure that the mounting plate is leveled horizontally.
1
1
1
1
1
1
2: Remove the mounting plate.
MOUNTING PLATE
CENTER HOLE
ELECTRICAL BOX
